Heltec nRF52840 Series

nRF52840 + SX1262 mainly optimized for Meshtastic system. Heltec’s nRF52840 + LoRa series is designed for ultra-low-power wireless applications, combining Bluetooth and long-range LoRa connectivity. It is well-suited for smart cities, agriculture, logistics, and IoT deployments, and fully supports the Meshtastic open-source ecosystem.

Usage Guide​

This Usage Guide provides detailed operating instructions for the nRF52840 series nodes, offering practical guidance and best practices to help users configure, manage, and deploy their devices more efficiently.

📄️ Mesh Node T096

Mesh Node T096 is a low-power development board integrating Bluetooth, LoRa, and GNSS. Based on the nRF52840 MCU, it features an SX1262 LoRa transceiver with PA (up to 28±1 dBm) and a UC6580 GNSS module for positioning. It adopts LDS antennas for compact and efficient RF performance, and is optimized for battery-powered applications. Fully compatible with Arduino and open-source mesh systems such as Meshtastic and MeshCore, it provides a reliable platform for mesh networking and tracking applications.
