Mesh Node T1

Mesh Node T1 is a compact LoRa terminal based on the nRF52840 and SX1262, featuring BLE/LoRa dual-mode connectivity, integrated GNSS and 9-axis IMU for positioning and motion awareness. It offers ultra-low power consumption (11 µA sleep), 1850 mAh battery capacity, and IP67 protection for extended outdoor use. Compatible with Meshtastic and MeshCore, it also supports Arduino-based customization.

Product Page

Product characteristicss

• nRF52840 (BLE) + SX1262 (LoRa) with 0.96inch TFTLCD
• 11µA Ultra-Low Power, 1850mAh Long Battery Life
• IP67 Industrial-Grade Protection
• Highly integrated LoRa terminal with GNSS, 9-axis IMU, and buzzer.

Important parameters

parameters	Mesh Node T1
Master and LoRa Chip	nRF52840 + SX1262
Memory	1M ROM; 256kB SRAM
Battery	1850mA Lithium battery
Bluetooth	Bluetooth 5, Bluetooth mesh, BLE
Power Consumption	Deep Sleep 11uA
Dimensions	85 * 55 * 9.5 mm

Important Resources

• Datasheet
• Schematic diagram
• nRF Development Framework
• Related links

Product Usage Guide

The following documentation will help you get started quickly with the product

• Install development environment
• Applied to LoRaWAN
• Applied to Meshtatic
• How to use license
