Mesh Node T114
Mesh Node T114 is a development board based on nRF52840 and SX1262, supports LoRa communication and Bluetooth 5.0, and provides a variety of power interfaces (5V USB, lithium battery and solar panel), optional 1.14 inch TFT display and GPS module as accessories.
Product characteristicss
- nRF52840 + SX1262 LoRa with Bluetooth
- Optional 1.14" TFT-LCD, 135*240, 262K colors
- Ultra-low power, 11 μA deep sleep
- Type-C USB, power management & protection
- Arduino-compatible, LiPo, solar, GNSS expansion
Important parameters
| parameters | Mesh Node T114 |
|---|---|
| Master and LoRa Chip | nRF52840 + SX1262 |
| Max. TX Power | 21±1dBm |
| Battery | 3.7V lithium battery power supply and charging |
| Bluetooth | Bluetooth LE: Bluetooth 5, Bluetooth mesh |
| Power Consumption | Deep Sleep 11uA |
| Dimensions | 50.80 * 22.86mm |
Important Resources
Product Usage Guide
The following documentation will help you get started quickly with the product
