HT-H7608 Wi-FI HaLow Router

Summary​

HT-H7608 is an innovative WiFi HaLow gateway from Heltec Automation designed to meet the needs of long-distance/high-speed data transmission for IoT applications. The gateway uses WiFi HaLow (IEEE 802.11ah) technology that operates in the sub-1 GHz unlicensed band, which has stronger penetration and larger coverage compared with the traditional WiFi standard.

Product characteristics​

  • Wi-Fi and Ethernet supported, WiFi HaLow and 2.4GHz dual-band design
  • Long-distance transmission capability
  • Supports access to a large number of devices
  • High transmission speed
  • Flexible networking methods, including AP, STA, Mesh, etc

Important parameters​

parametersHT-H7608
MCUMT7628
Wi-Fi HaLow StandardIEEE 802.11ah
Wi-Fi StandardIEEE 802.11b/g/n
Flash32M
RAM128M
Power Supply5V/1~2A DC

Important Resources​
