Wifi Kit 32
WiFi kit 32 is a classic IoT Dev-board designed&produced by Heltec Automation(TM), It’s a highly integrated product based on ESP32(including WiFI and BLE), Li-Po battery management system,0.96” OLED are also included. It’s the best choice for smart citites,farms homes,and IoT makers.
Product characteristicss
- ESP32-S3FN8 dual-core, 240 MHz, Arduino compatible
- Type-C USB, with power, ESD, and short-circuit protection
- Battery port with management, charge/discharge, protection, auto-switch
- Wireless + display, Wi-Fi, Bluetooth, 0.96" OLED
- CP2102 USB-to-serial, easy programming/debugging
Important parameters
| parameters | Wifi Kit 32 |
|---|---|
| Master Chip | ESP32-S3FN8 |
| USB to Serial Chip | CP2102 |
| Battery | 3.7V lithium battery power supply and charging |
| Bluetooth LE | Bluetooth 5, Bluetooth mesh |
| Power Consumption | Deep Sleep 10uA |
| Dimensions | 50.2 * 25.5* 10.2 mm |
Important Resources
Product Usage Guide
The following documentation will help you get started quickly with the product
