Wireless Stick Lite
The HTIT-WSL is a development board that integrates Wi-Fi, Bluetooth, and LoRa connectivity. Unlike the WiFi LoRa32, this version is designed without an OLED display to better suit customers who do not require it. Powered by the ESP32-S3FN8 MCU and Semtech SX1262 LoRa transceiver, the board offers full compatibility with Arduino®, making it easy for users to perform secondary development and create a wide range of applications.
Product characteristics
- ESP32-S3FN8 MCU, support Wi-Fi, LoRa and BLE
- SX1262 LoRa node chip, compatible with Meshtastic
- Integrated CP2102 USB to serial port chip
- Features Type-C USB, multiple protections, and built-in battery management
- With good RF circuit design and basic low-power design (sleep current ≤800uA)
Important parameters
| parameters | Wireless Stick Lite(V3) |
|---|---|
| Master and LoRa Chip | ESP32-S3FN8 + SX1262 |
| DisplayResolution | 128(H)x296(V) Pixel |
| Max. TX Power | 21±1dBm |
| Bluetooth | Bluetooth 5(LE) |
| Power Supply | 3 ~5V (USB), 3 ~4.2(Battery) |
| Dimensions | 88mm * 36.6mm * 12mm |
Important Resources
Product Usage Guide
The following documentation will help you get started quickly with the product
